Mono Solar Cell IP68 Rated Junction Box 575w 605w Watt PV Module Half Cell Solar Panel

Model Number : AS575~605M10-156

Place of Origin : Anhui, China

Cell size : 182mmx182mm

Type : PERC, Half Cell, Bifacial, Double-glass, All Black

Panel Dimensions : 2465*1134*35MM

Panel Efficiency : 21.65%

Warranty : 25 Years, 25 Years

Application : Solar Power System

Product name : solar PV module

Cell Type : Mono Solar Cell

Certificate : CE, TUV, INMETRO,

Frame : Anodized Aluminium Alloy

Junction Box : IP68 Rated

Keyword : Photovoltaic module

Number of Cells : 156 cells

Weight : 30.5KG

MOQ : 1000 watts

Price : $0.14/watts 1000-9999 watts

Contact Now

Mechanical Data
ELECTRICAL PARAMETERS
ELECTRICAL PARAMETERS
Rated Maximum Power at STC
575W
585W
595W
600W
605W
Open Circuit Voltage (Voc)
51.02
51.28
51.54
51.67
51.8
Maximum Power Voltage (Vmp)
43.04
43.34
43.64
43.79
43.94
Short Circuit Current (Isc)
14.25
14.39
14.53
14.60
14.67
Maximum Power Current (Imp)
13.36
13.50
13.64
13.71
13.78
PV Module Efficiency (%)
20.57
20.93
21.29
21.47
21.65
STC: Irradiance 1000W/m2, Cell Temperature 25°C, Air Mass AM1.5.
*Measuring Tolerance: ±3%.
STC: Irradiance 1000W/m2, Cell Temperature 25°C, Air Mass AM1.5.
*Measuring Tolerance: ±3%.
Layout
156( 6 × 26)
Junction Box
Split junction box, IP67, 3 diodes
Weight
30.5KG
Cable Length
300mm (+) / 300mm(-)
Cable Size
4mm²(IEC)
PV Size
2465×1134×35mm
Packaging
30 pcs / pallet
540 pcs / 40HQ container
